Vibrating Feeder

Vibrating Feeder

Processing capacity: 1-105t/h
Feeding size: 125-250mm
Feed opening: 150×250-300×1300mm
Motor power: 5.5-55kw
Total weight: 0.8-15.6t

Free download pdf (Product information) (869.00KB) Get price list

0086-0371-63313738/0086-18039114854

We will provide you with the best quality service.If you are interested in our products,
you can click the button and contact us.
market@hxjq.com Send Enquiry

Vibrating Feeder Overview

Vibrating Feeder is designed and built to withstand the toughest work in a quarry or mine by matching different applications. This vibratory feeder series is designed particularly for continuous use with any hard and abrasive materials through uniform flow. Vibrating grizzly feeder works to continuously and evenly feed lumpy, granular and powdery materials from hopper to belt conveyer, bucket elevator, screens and crushing machines, etc.

Steeples regulation is available for our vibrating feeder to automatically and centrally control the feeding volume. We produce specialized China vibrating feeder, ore vibrating feeder, disk feeder, etc.

vibrating feeder

Vibrating Feeder Application

The Vibrating Feeder is mainly used to feed material into the primary crusher homogeneously and continuously. Meanwhile, it can screen material, making the crusher more powerful. Proven performance and maintenance free operation make our vibrating feeders the first choice in feeders for the most demanding applications including public utilities, mining, metals production, food processing, cement, and other industries.

Vibrating Feeder Benefits

1. Our vibrating feeder is of highest capacity for the same deck size in industry
2. Sub-resonance tuning to guarantee efficient, continued operation as deck liners wear
3. Simple structure, easy adjustment and maintenance.
4. Infinite variety of sizes and custom configurations
5. Our vibrating feeder is added closed frame; it can largely reduce pollution and noise.

Parameters Type

Model Max.
Feeding
Size
(mm)
Processing
Capacity
(t/h)
Motor
Power
(kw)
Obliquity
of material
trough
(°)
Trough
size
(mm)
Dimensions
(L×W×H)(mm)
GZD-650×2300 300 80-100 1.1×2 10-20 650×2300 2300×1360×780
GZD-750×2500 350 100-130 1.5×2 10-20 750×2500 2500×1460×780
GZD-850×3000 400 120-150 3×2 10-20 850×3000 3110×1800×1600
GZD-1000×3600 500 150-200 3.7×2 10-20 1000×3600 3850×1950×1630
GZD-1100×3600 580 240-300 3.7×2 10-20 1100×3600 3600×2050×1660
GZD-1300×3600 650 450-600 7.5×2 10-20 1300×3600 3900×2350×1750
GZD-1500×3600 1050 450-1000 7.5×2 10-20 1500×3600 3900×2000×1750
GZD-2000×3600 1200 550-1000 10×2 10-20 2000×3600 3600×2000×1750
GZD-2500×5000 1500 650-1500 18×2 10-20 2500×5000 5000×2500×1800
ZSW-380×95 500 100-180 11 0-10 3800×960 3800×1640×1320
ZSW-490×110 630 150-400 15 0-10 4900×1100 4980×1830×1320
ZSW-490×130 750 400-700 22 0-10 4900×1300 4980×2580×2083
ZSW-600×130 750 400-700 22 0-10 6000×1300 6082×2580×2083
ZSW-600×150 800 500-900 30 0-10 6000×1300 6086×2662×1912
ZSW-600×180 900 700-1300 37 0-10 6000×1500 6310×3262×2230
ZSW-600×200 1200 800-1500 45 0-10 6000×2000 6086×2662×1912
